FLOW Dump Valve

The AQUALON FLOW Dump Valve is a precision-engineered high-pressure valve designed for use in FLOW waterjet cutting systems. It provides fast and controlled pressure relief by safely diverting high-pressure water from the cutting circuit to the dump line. This function is essential for system protection, safe operation, and accurate cutting control. Manufactured from high-strength, corrosion-resistant materials, the dump valve ensures reliable performance, long service life, and consistent operation in demanding industrial environments.

Sort

Products per page

Bleed down repair kit, 004694-1

10935
Net Weight: 45 g

Bleed down valve body, 001822-1

11035

Bleed down valve assembly, C-5841-1

12011

Bleed down repair kit, 015084-1

12365

Adapter, bleed down, B-5975-1

12604

87K Bleed-down Valve Body, 011742-1

12769

Assy, High Pressure Valve, C-2740-1

12819

Body, bleed down valve, B-8427-1

13256

Components Included – FLOW Dump Valve

1. Valve Body

Precision-machined valve body
Designed for use in FLOW high-pressure waterjet systems
High-pressure and corrosion-resistant construction

2. Valve Spool / Valve Piston

Moving control element for pressure relief
Enables fast and controlled opening and closing of the high-pressure circuit

3. Valve Seat

Precision-ground sealing surface
Ensures reliable sealing under extreme operating pressures

4. Seal Kit

Dynamic and static sealing elements
O-rings, backup rings, and high-pressure seals
Ensures leak-free operation in the high-pressure circuit

5. Return Element

Spring providing defined valve return
Supports consistent and repeatable switching cycles

6. Porting and Control Passages

High-pressure, low-pressure, and return ports
Integrated control passages according to FLOW specifications

7. Fastening and Retaining Elements

Bolts, plugs, and retaining rings
Secure the complete valve assembly
