HP Gauge 80000 PSI

References: 10085884, 20468118, 400126-1, A-1456

UHP Gauge - High pressure gauge indicating operating pressure. The high pressure gauge is the best way to quickly evaluate machine performance and the only way to truly know what the cutting pressure is.  This is a high quality gauge for long life. Simply add a "T" to an existing line and put this at the end of a short nipple, as close to the head (but out of the way) as possible. Typically it is mounted above the head on the gantry for easy viewing or at the pump-end of the whip but high enough to easily see.  It will become a key, valuable part to the machine.

1/4" F connection on bottom.

152,4 mm / 6" Diameter

Article number: 11944

Net Weight: 2690 g
