Base body , HD310100

Base Body HD310100 – Waterjet Spare Part

This is the main housing component for an abrasive waterjet cutting head assembly used in industrial waterjet cutting machines.

General Info:

• Product name: Base body

• Part number: HD310100

• Article number: 11705

• A core structural part of the waterjet cutting head assembly, typically forming the backbone that all other cutting head internals attach to.

Function & Role:
In an abrasive waterjet system, the cutting head is where ultra-high-pressure water is converted into a precise, high-velocity cutting stream mixed with abrasive particles (like garnet). The base body serves as the main housing or body of that cutting head, providing:

• A sturdy, high-pressure-rated structural framework to withstand the intense internal pressures involved in waterjet cutting.

• Mounting points and flow passages for connecting the high-pressure inlet, abrasive inlet, mixing components, and nozzle/focusing tube (which together create the abrasive jet).

• Alignment and sealing surfaces for internal components like the orifice, mixing chamber and focusing tube to ensure efficient jet formation without leaks.

How It Fits:
In a complete abrasive head:

1. High-pressure water enters the cutting head housing.

2. The base body supports the orifice where water is turned into a high-velocity stream.

3. An abrasive feed port and mixing chamber integrate abrasive particles into the water stream.

4. The focusing tube (nozzle) directs the abrasive waterjet onto the workpiece.

The HD310100 base body is sold as a replacement or spare part for maintaining or rebuilding waterjet cutting heads in industrial cutting systems, helping keep machines operating reliably.
